Robust stainless emergency telephone with full metal keypad for Prison,Bank,Airport

FOB Reference Price:Get Latest Price
  • 1 - 999 Sets
    US $150.00
  • >=1000 Sets
    US $90.00
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
J&R
Model Number:
JR205-FK
Type:
Inmate Telephone
Voice Mail:
Yes
Material:
Stainless Steel
Certificate:
FCC RoHS CE(EMC,LVD) SASO ISO9001
Warranty:
2 Years
Operating temperature:
-40°C to +70°C
Storage temperature:
-40°C to +70°C
Protection type:
IP55-IP65
Hookswitch:
Magnetic reed hook switch to reduce parts subject to wear
Application:
Prison,Jail,Correctional Center
Communication Type:
Full duplex
Ringer volume:
90~95dB(A) at a distance of 1 m
SupplyAbility
SupplyAbility:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Unit size: 300*120 *101(mm)
Packaging materials: pearl cotton, carton
Net weight: 3KG
Gross weight: 3.5KG
Port
Shenzhen
Lead Time :
3 days

Robust stainless emergency telephone with full metal keypad for Prison,Bank,Airport



Model No: JR205-FK

Product Description
This Telephone is housed in stainless steel box and manufactured to a high standard, it is offer increased resistance to vandalism, and ensure that the primary function of communications is maintained at all times, resulting in a highly reliable product with a long MTBF.

APPLICATION:

Ideal for Bank,Prison,Metro, Railway, Highway side, Marine, Mining, Tunnels, Steel Plant,Chemical plant,Power plant indoor: Airprot, transtation, bank,koisk, elevator, university, hotel, hospital, plant, oil and gas,Outdoor station,Bridge,Mine, Army,and related industrial application, etc.

FEATURES

Standard Analogue phone,available for VoIP/SIP Phone

Can be used on most PBX systems as an extension phone

Weather protection IP65

Tamper resistant fixings,Fast-fit terminal connection

Magnetic reed hook switch to reduce parts subject to wear

Armored modular keypad with metal buttons and bezel that is water, fire and shock resistant

Calling card service compatible

Can be programmed remotely by tone phone or locally via keypad

Non-volatile memory,Built in ringer can be left on or turned off.

Weatherproof and corrosion resistant handset

Stainless steel armoured handset cord

Built-in user controlled volume “LOUD” button for ADA mandated volume control (user must have control of volume amplification AND volume must reset to normal with hang up to meet ADA requirements).

Telephone line powered for Analog phone

DC 5V powered or PoE

Connection: RJ45 Ethernet socket through IP67 plug connector.

Quality of Service (QoS): ensuring optimal delivery of voice

Type of Service (ToS): high throughput and reliability (RFC3168)

SIP (Session Initiation Protocol) RFC3261

nbuilt redundancy: able to make diversion calls to 2nd PBX

TR069 (Technical Report 069): for advanced status monitoring and control

Configuration: web interface or server based configuration file. Static IP address provisioning or DHCP.

Mass configuration available.

This phone can be easily flush mounted without the need for a separate mounting device.

CE, FCC,ISO9001,ROSH compliant





Production Details:



Technical Data

Analogue Version

Power SupplyFrom the analogue telephone network
Supply Voltage        24 VDC to 65 VDC
Supply Current20 mA DC to 100 mA DC
Ringer Volume- 80dB(A)  at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)
Dialing Method

DTMF mode in accordance with ITU-T recommendation Q.23.



SIP Version

Power SupplyPoE or 12V DC
Power Consumption-Idle:1.5W
-Active:1.8W
SIP ProtocolSIP 2.0 (RFC3261)
Support CodecG.711 A/U, G.722 8000/16000, G.723, G.729
Communication TypeFull duplex
Ringer volume- 90~95dB(A)  at a distance of 1 m
- 110dB(A) at a distance of 1 m (for external horn speaker)



3G Version

Power Supply12V DC
Power Consumption-Idle:0.3W
-Active: 1.5W
Communication TypeFull duplex
Ringer volume90~95dB(A)  at a distance of 1 m
Program MethodRemote programming by SMS
Frequency A version:

- Dual-Band WCDMA/HSDPA 850/1900MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

E version:

- Dual-Band UMTS/HSDPA 900/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz

J version:

- Dual-Band UMTS/HSDPA 850(800)/2100MHz
- Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz



Ambient conditions

Protection typeIP 66 as per EN60529
Operating temperature-25°C to +70°C
Storage temperature-25°C to +85°C
DIMENSION



CERTIFICATIONS:

Packaging & Shipping

Unit size: 300*120 *101(mm)
Packaging materials: pearl cotton, carton
Net weight: 3KG

Gross weight: 3.5KG
